ShimanoXTR RD-M9100 Rear Derailleur
$256.99

Item # SHI00L9

Select options
  • Cancel
  • Select options
  • Stealth Gray, GS 12 Speed ($256.99)
  • Stealth Gray, SGS 12 Speed ($256.99)
  • 100% Guaranteed Returns
  • Free 2-Day Shipping
    on orders over $50

Item # SHI00L9
Description

XTR RD-M9100 Rear Derailleur

With the release of the XTR M9100 12-speed drivetrain, Shimano jumps right back to the front of the pack by expanding the available gear range and offering better shifting performance than ever before. The new XTR RD-M9100 Rear Derailleur is specifically optimized for Shimano's new wide range cassettes, and features several updates that ultimately lead to smoother and quieter drivetrain operation. It comes in two different cage lengths depending on what gear ratio you choose, letting you select the best option to suit your riding style and preferences.

The M9100 Rear Derailleur sees improved chain stability and reduced friction thanks to larger 13t pulley wheels, making it better able to withstand full-force pedaling while shifting gears as smoothly as ever. Shimano was also able to decrease the rear derailleur tension in the lower gear positions, preventing the high chain tension that causes excess friction and noise, and thus a loss of efficiency. The Shadow RD+ clutch system provides excellent chain retention in rough terrain, and keeps annoying chain slap to a minimum. Lastly, the addition of a protective bumper to the inside of the derailleur cage quiets operation even further by cushioning the sound of any chain rub.

There are two options available depending on your desired setup. The longer cage SGS model is required for the 10 - 51 tooth XTR 12-speed cassette, but also works with the 10 - 45t Rhythm-Step 12-speed cassette. The GS model features a shorter cage with 28mm more ground clearance for rocky, rooty, and aggressive terrain. It's designed exclusively for the 12-speed 10 - 45t Rhythm-Step cassette.

  • XTR rear derailleur sees improved shifting & quieter operation
  • Decreased chain tension in the low gears to improve efficiency
  • Larger 13t pulley wheels for better chain stability and shifting
  • Shadow RD+ clutch minimizes chain slap and prevents chain drop
  • Protective bumper in the cage quiets the sound of chain rub
  • SGS model is designed for 12-speed 10 - 51t XTR cassette
  • GS model is designed for 10 - 45t XTR cassette
  • Gradients on back of cage for easier limit screw setup
Tech SpecsWeight
Tech Specs
Material
aluminum
Cage Length
[sgs] long, [gs] short
Capacity
[sgs] 10 - 51t, [gs] 10 - 45t
Gearing
[sgs] 1 x 12, [gs] 1 x 11, 1 x 12
Compatibility
[chain] XTR CN-M9100, [cassette] XTR CS-M9100, [shifter] XTR SL-M9100-R, XTR SL-M9100-IR
Recommended Use
mountain
Manufacturer Warranty
3 years
Weight

Actual Weight

Actual weights are measured in-house by the Competitive Cyclist team.

Have questions? Chat with a Gearhead

Grams

Oz

Stealth Gray, GS 12 Speed
240g
8.47oz
Stealth Gray, SGS 12 Speed
243g
8.57oz

Claimed Weight

Claimed weights are provided by the vendor.

Have questions? Chat with a Gearhead

[sgs] 240g, [gs] 237g
