New Arrival
Vala Lite CC XX Transmission Reserve E-Bike
Add Ons
Join Summit Club+ and
Santa Cruz Vala CC XX AXS Lite RSV lightweight trail E-Bike, DT Swiss 240 hubs, SRAM XX wireless
What Our Gearhead® Experts Are Saying:
"The Lite build the four-bar suspension, the Bosch CX motor, and the geometry that make the Vala work, and strips weight from the places that affect how the bike moves rather than how it performs. DT Swiss 240 hubs reduce rotating mass at both wheels, the carbon crankset cuts weight at the bottom bracket, and the Fox 36 keeps front-end feel without the added heft of the 38. With the grams shed, it accelerates and changes direction more like a trail bike than a full-power E-bike."
Why We Like It
The SRAM XX AXS T-Type drivetrain is the spec that earns the most attention on this build beyond the weight savings. Wireless shifting with no separate derailleur battery, a cassette range that handles everything from steep technical climbing to fast singletrack, and the precision and reliability that make XX the benchmark for wireless mountain drivetrains.
Heads up! We do our best to keep bike specs and images current, but occasional component changes can happen without warning, and sometimes the photos might not show the exact build you'll receive. If you want to double-check the details, our Gearhead® Experts are always here to help.
Details
- Lightweight trail E-bike for all-day riding and technical terrain
- Bosch Performance Line CX motor — enough power and range for all-day trail riding without a shuttle
- Four-bar suspension, 150mm rear travel — independently adjustable geometry and progression flip chips
- Fox 36 Factory fork, 160mm — Grip X2 damper in a lighter package than the standard Vala build
- Slack 64.2° head angle — trail-focused geometry that stays confident on steep terrain without sacrificing agility
- CC Carbon frame, MX wheel sizing — 29-inch front, 27.5-inch rear for trail handling on a full-power platform
- SRAM XX AXS T-Type 12-speed drivetrain — wireless shifting with no separate derailleur battery required
- Reserve 30 HD carbon wheels — lightweight carbon rims on DT Swiss 240 hubs front and rear
- Item #SNZK1RF
- Frame Material
- Carbon CC
- Suspension
- Four-bar
- Rear Shock
- Fox Float X Factory, 205 x 60mm
- Rear Travel
- 150mm
- Fork
- Fox 36 Float Factory, Grip X2
- Front Travel
- 160mm
- Headset
- Chris King DropSet 3 Integrated
- Shifters
- SRAM AXS Pod Controller Rocker
- Rear Derailleur
- SRAM XX Eagle AXS T-Type, 12-speed
- Modes
- Eco, Tour, eMTB, Turbo
- Drive System
- Bosch Performance Line CX BDU38
- Motor Power
- 600W
- Battery Type
- Bosch PowerTube 600Wh
- Battery Energy
- 600Wh
- Max Torque
- 85Nm
- Max Speed
- 20mph
- Crankset
- e13 Helix Race Carbon e*spec
- Chainring Sizes
- 34t
- Crank Arm Length
- 160mm
- Bottom Bracket
- ISIS
- Cassette
- SRAM XX Eagle T-Type
- Cassette Range
- 10-52t
- Chain
- SRAM XX Eagle T-Type Flattop, 12-speed
- Brakeset
- SRAM Maven Ultimate Carbon
- Brake Type
- hydraulic disc, 6-bolt
- Rotors
- SRAM HS2, 200mm
- Handlebar
- OneUp Carbon Bar, 35mm clamp
- Handlebar Rise
- [small] 20mm, [medium, large, x-large, xx-large] 35mm
- Handlebar Sweep
- 9° back, 5° up
- Handlebar Width
- [small] 760mm, [medium, large, x-large, xx-large] 800mm
- Grips
- Santa Cruz house grips
- Stem
- Industry Nine A35
- Stem Length
- 40mm
- Saddle
- WTB Silverado Medium Fusion, Stainless
- Seatpost
- OneUp Dropper Post, 31.6mm
- Seatpost Travel
- [small] 120mm, [medium] 180mm, [large] 210mm, [x-large, xx-large] 240mm
- Wheelset
- Reserve 30 HD Carbon, 28H
- Hubs
- [front] DT Swiss 240, [rear] DT Swiss 240 DEG DF, XD
- Front Axle
- 15 x 110mm Boost
- Rear Axle
- 12 x 148mm Boost
- Tire Clearance
- 2.5in
- Tires
- [front] Maxxis Assegai 3C MaxxGrip EXO+, [rear] Maxxis Minion DHRII 3C MaxxTerra EXO+
- Tire Size
- [front] 29 x 2.5in, [rear] 27.5 x 2.5in
- Pedals
- not included
- Extras
- tool mount
- Claimed Weight
- 45.5lb
- Activity
- trail, enduro
- Manufacturer Warranty
- [frame] 5 years
