Vala Lite CC XT Di2 Reserve E-Bike
Add Ons
Join Summit Club+ and
Santa Cruz Vala CC XT Di2 Lite RSV trail E-Bike with hardwired Shimano XT Di2 and Fox 36 Grip X2
What Our Gearhead® Experts Are Saying:
"The Fox 36 with Grip X2 damper keeps the front end precise and tunable on technical terrain without adding weight where I'd feel it most on a long climb. The Shimano XT Di2 hardwires directly to the Bosch drive unit, so the derailleur draws power from the main battery and the Bosch Flow app unlocks auto-shifting modes that adjust gearing based on motor output."
Why We Like It
The Lite build philosophy starts with the frame, motor, and suspension unchanged and works outward from there. Swapping the Fox 38 for the 36 and running EXO+ tire casings front and rear reduces weight at the points where it most directly affects how the bike accelerates and handles direction changes. The Shimano XT Di2 integration with the Bosch system adds a layer of intelligence to the drivetrain that suits the Lite's trail-focused character.
Heads up! We do our best to keep bike specs and images current, but occasional component changes can happen without warning, and sometimes the photos might not show the exact build you'll receive. If you want to double-check the details, our Gearhead® Experts are always here to help.
Details
- Lightweight trail E-bike for technical singletrack and all-day riding
- Bosch Performance Line CX motor and 600Wh battery — full-power assist without shuttle dependency
- Four-bar suspension, 150mm rear travel — flip chip adjustable for geometry and progression independently
- Fox 36 Factory fork, 160mm — Grip X2 damper keeps the front end precise without added heft
- Slack 64.2° head angle — slack enough for steep terrain, responsive enough for fast singletrack
- CC Carbon frame, MX wheel sizing — 29-inch front, 27.5-inch rear balances traction with rear-end agility
- Shimano XT Di2 12-speed — hardwired to the Bosch drive unit with auto-shifting via the Bosch Flow app
- Reserve 30 HD carbon wheels — carbon rims on DT Swiss 350 hubs
- Item #SNZK1RE
- Frame Material
- Carbon CC
- Suspension
- Four-bar
- Rear Shock
- Fox Float X Factory, 205 x 60mm
- Rear Travel
- 150mm
- Fork
- Fox 36 Float Factory, Grip X2
- Front Travel
- 160mm
- Headset
- Cane Creek 50 IS Integrated
- Shifters
- Shimano Deore XT M8250 Shift Switch
- Rear Derailleur
- Shimano Deore XT Di2 M8260, 12-speed
- Modes
- Eco, Tour, eMTB, Turbo
- Drive System
- Bosch Performance Line CX BDU38
- Motor Power
- 600W
- Battery Type
- Bosch PowerTube 600Wh
- Battery Energy
- 600Wh
- Max Torque
- 85Nm
- Max Speed
- 20mph
- Crankset
- e13 Helix Race Alloy e*spec
- Chainring Sizes
- 34t
- Crank Arm Length
- 160mm
- Bottom Bracket
- ISIS
- Cassette
- Shimano XT M8200
- Cassette Range
- 10-51t
- Chain
- Shimano XT M8100, 12-speed
- Brakeset
- Shimano XT M8220
- Brake Type
- hydraulic disc, 6-bolt
- Rotors
- Shimano RT750, 200mm
- Handlebar
- OneUp Carbon Bar, 35mm clamp
- Handlebar Rise
- [small] 20mm, [medium, large, x-large, xx-large] 35mm
- Handlebar Sweep
- 9° back, 5° up
- Handlebar Width
- [small] 760mm, [medium, large, x-large, xx-large] 800mm
- Grips
- Santa Cruz house grips
- Stem
- Santa Cruz CNC
- Stem Length
- 40mm
- Saddle
- WTB Silverado Medium Fusion, CroMo SL
- Seatpost
- OneUp Dropper Post, 31.6mm
- Seatpost Travel
- [small] 120mm, [medium] 180mm, [large] 210mm, [x-large, xx-large] 240mm
- Wheelset
- Reserve 30 HD Carbon, 28H
- Hubs
- [front] DT Swiss 350, [rear] DT Swiss 350 DEG DF, MicroSpline
- Front Axle
- 15 x 110mm Boost
- Rear Axle
- 12 x 148mm Boost
- Tire Clearance
- 2.5in
- Tires
- [front] Maxxis Assegai 3C MaxxGrip EXO+, [rear] Maxxis Minion DHRII 3C MaxxTerra EXO+
- Tire Size
- [front] 29 x 2.5in, [rear] 27.5 x 2.5in
- Pedals
- not included
- Extras
- tool mount
- Claimed Weight
- 46lb
- Activity
- trail, enduro
- Manufacturer Warranty
- [frame] 5 years
