How to pair and update SRAM AXS and Shimano Di2 (step-by-step)

Keep your electronic groupset reliable and responsive: this guide walks you through the essentials of pairing, charging, and updating SRAM AXS and Shimano Di2 so your shifting stays dialed. About 30–60 minutes on the bench.

Why pairing & firmware updates matter

Electronic drivetrains are reliable — when they’re paired correctly and running current firmware. Get this wrong and you’ll see missed shifts, dropped gears, or unpredictable behavior mid-ride — exactly when you don’t want it. This guide shows a safe, repeatable process for charging, pairing, and updating SRAM AXS and Shimano Di2 systems. Estimate: about 30–60 minutes on the workbench.

WARNING: Incorrect installation, pairing, or firmware updates for electronic groupsets can cause loss of control and serious injury. If you are not confident performing these procedures, take your bike to a qualified mechanic.

Related Categories: Groupsets (check compatibility and manuals before you start); Electronics & Power Meters (battery care and diagnostics); Wheels & Hubs (verify axle and dropout compatibility before reassembly)

Before You Start — prerequisites and safety

Park the bike on a stable workstand or a level surface.

Have a clean, well-lit bench and your phone or laptop ready.

Confirm charger and battery condition. Don’t attempt firmware updates on a partially charged battery.

For any adjustments to brakes, steering, or load-bearing bolts, consult your component manuals or a shop tech.

Tools & Supplies

Phone or tablet with Bluetooth and the latest OS; laptop with USB (optional for desktop utilities).

SRAM AXS app (mobile) and/or AXS Web utility.

Shimano E-Tube Project app (mobile/desktop) and a compatible interface where required.

Charger and batteries for both systems.

3mm/4mm/5mm hex keys and a calibrated torque wrench (verify with your component's manual — values vary by manufacturer and material).

Clean rag and isopropyl alcohol (for connector contacts).

Steps — General prep (do this for either system)

  • Charge batteries — Fully charge all batteries (shifter, derailleur, external battery if used). Low power can interrupt updates.

  • Inspect connectors and wiring — Clean any exposed contacts with isopropyl alcohol and inspect cables for chafing. Replace frayed wires.

  • Put the bike in a safe, stable work position — Remove the chain from the cassette only if the manufacturer recommends it for a firmware operation. Most updates do not require drivetrain removal.

Step-by-step: SRAM AXS (high-level)

  • Install and open the AXS app — Download the latest SRAM AXS app to your phone. Create or sign into your SRAM account and grant Bluetooth permissions.

  • Wake the system — Power-cycle the battery or press the derailleur's wake button (if present) so the app can discover the component.

  • Pair devices in the app — Follow the AXS app prompts to add a new bike and pair front/rear derailleurs and shifters. Accept pairing requests when prompted.

  • Check for firmware updates — Once paired, the app will typically indicate available firmware updates. Follow on-screen instructions and do not interrupt the process.

  • Finalize and test — After updating, verify shift indexing and test under light pedaling on the stand. Reboot the system if the app suggests it.

Step-by-step: Shimano Di2 (high-level)

  • Install E-Tube Project (mobile or desktop) — Shimano’s E-Tube is the official path for diagnostics and firmware. Use the mobile app or the desktop E-Tube Project with the appropriate interface (check your Di2 generation and required adapter).

  • Connect the bike — Connect via the wireless unit (if equipped) or by plugging the diagnostic interface into the junction box. Allow the software to detect components.

  • Pair and register components — The software will list connected Di2 components. Follow prompts to register the bike and components.

  • Install firmware updates — If updates are available, follow E-Tube’s instructions carefully. Keep the bike powered throughout and avoid closing the app or sleeping the device mid-update.

  • Confirm settings — Re-check shift mode (e.g., Synchro Shift vs. manual), lever assignments, and multi-shift options in the app.

Validation — What good looks like

Shifts are crisp under light pedaling on the stand and under a short road test.

No error lights or warning codes in the app.

Battery reports full or acceptable charge and holds charge during a brief ride.

Gear indexing is accurate across the cassette; no chain rub on the front derailleur.

Troubleshooting (common issues + fixes)

  • 1. Device not discovered — Kill and reopen the app, power-cycle the battery, and retry Bluetooth. If Di2, ensure the diagnostic interface or wireless unit is seated properly.

  • 2. Update fails or stalls — Reboot phone/laptop and the bike, ensure batteries are fully charged, and retry. If failures persist, consult the app logs and consider doing the update on a desktop utility.

  • 3. Intermittent shifting after update — Re-run automatic indexing in the app/utility. Check wiring junctions for moisture or loose plugs.

  • 4. Battery drains faster after firmware update — Let the system complete one charge cycle and re-evaluate. If the drain continues, contact the manufacturer or your shop for diagnostics.

  • Gearhead Tip: Keep a small notebook in the garage. Record firmware versions before and after updates so you can roll back (where supported) or explain behavior to tech support.

When to Stop & Seek a Shop

The update process reports persistent errors you can’t resolve.

You find physical damage to a derailleur, battery, or wiring.

You’re uncomfortable opening junction boxes or replacing batteries.

Any brake or steering component was loosened or disturbed during the work — have a pro verify torque and safety-critical adjustments.

Post-work safety checks (do these before your next group ride)

Test shifts across all gears while pedaling under low load.

Verify brakes work and rotors are true (if touched during the workbench session).

Confirm batteries are secure and connectors are locked.

Take a short low-speed test ride and re-check shifting.

Sources

SRAM AXS app and support pages.

Shimano E-Tube Project (mobile and desktop) documentation.

Component owner’s manuals and junction-box guides.

Internal Links

Takeaways

  • Always fully charge batteries before attempting firmware updates or pairing.

  • Use the official app or desktop utility for pairing and firmware — don’t rely on third-party tools.

  • Record firmware versions and test shifts on the stand and on a short ride before joining a group ride.

  • Seek a qualified mechanic if updates fail, wiring is damaged, or you’re unsure about safety-critical adjustments.

FAQs

Can I update SRAM AXS and Shimano Di2 on the road?

No: firmware updates should be done on a bench with stable power and a charged battery. Interruptions or low power can brick components.

How often should I check for firmware updates?

Check whenever you notice shifting oddities, after installing new components, or periodically during the season. Updates also add features or fix bugs.

Will updating firmware change my lever assignments or settings?

Sometimes. Note current settings before updating. After an update, verify lever mapping, multi-shift, and Synchro/manual modes.
