Rocky Mountain
Altitude C Frameset

Be the first to review


Find your size


Customize Your Build

Why We Like The Rocky Mountain Altitude C Frameset

Rocky Mountain's newly redesigned Enduro steed has arrived and is more capable than ever. The Altitude is now equipped with Rocky Mountain's new LC2R suspension system, which features a low pivot and a counter-rotating link design for enhanced traction, efficiency, and a lower center of gravity. A new one-piece rear triangle, paired with shorter links and more robust bearings, enhances durability and efficiency. Meanwhile, a revised rate curve and enhanced anti-squat characteristics improve suspension kinematics over the previous Smoothlink platform. 160mm of LC2R suspension plows down the steep descents, rides high in its travel, and still has enough juice in the tank to climb efficiently. The revised Ride-4 adjustment system simplifies the adjustment range over their previous Ride-9 and gives us four distinguishable geometry adjustments to tune our ride feel. The flip chip on the rear shock link also allows us to make the Altitude into a mixed wheel setup for faster turning, more agility, and extra clearance. A reach-adjust headset cup offers a 3-position adjustment so we can dial in our fit, and Rocky Mountain added in their new Penalty Box 2.0 internal frame storage to store a spare tube, snacks, and tools inside the bike's frame. The Carbon frameset is equipped with Fox's Factory X2 rear shock for top-tier suspension performance and loads of adjustment to fine-tune our feel. Integrated protectors at the upper and lower downtube, chainstay, and seat stay keep our frame protected.

*Due to a high demand in the global supply chain and bike industry since the start of the pandemic, material weight and exact components are subject to change. We are working diligently to keep tech specs updated, and any adjustments will be of equal or better spec level, If you have any questions, reach out to a Gearhead by chatting online or calling 1-888-276-7130.


  • Enduro race frameset with a revised suspension system
  • 160mm of LC2R suspension is plush on the downhill, yet efficient on the climbs
  • Carbon frame has size-specific tunes for an optimal ride feel
  • Fox Factory X2 rear shock for super tunable, top-tier performance
  • Ride-4 adjustment system adjusts our geometry
  • Penalty Box 2.0 internal frame storage stores tubes and tools
  • Item #RMBB01O
Frame Material
Smoothwall Carbon fiber
Wheel Size
Rear Shock
Fox Factory Float X2
Rear Travel
Fork Travel
[recommended] 170mm
Head Tube Diameter
1 1/8in - 1 1/2in
Headset Included
FSA ZS56|66 reach adjust, 0mm cups installed, +/- 5mm cups included
Bottom Bracket Type
Cable Routing
internally guided
Brake Type
Post Mount, Disc
Compatible Components
tapered 170mm fork, boost 29in wheels, Post Mount brakes
Seatpost Diameter
Rear Axle
12 x 148mm Boost
Tire Clearance
[rear] 2.5in
downtube protector, chainstay protector, shuttle guard, SRAM UDH compatible, Ride-4 adjustment system, internal cable routing, 3-position reach adjust headset, Penalty Box 2.0, MX-compatible frame
Manufacturer Warranty
5 years
