Shuttle SL Team XTR Carbon Wheel e-Bike

Be the first to review
$11,599.00
Color:Desert Sage Green

Size:

GeometryFind your size

Quantity


Why We Like The Pivot Shuttle SL Team XTR Carbon Wheel e-Bike

Pivot is known for high-performance mountain bikes, and the Shuttle SL EMTB is no different. The first things we noticed about the Shuttle SL were its low weight and crisp handling. Utilizing Pivot’s full carbon hollow core frame construction and the 9.3lb FAZUA Ride 60 system, Pivot was able to create a super light trail EMTB that rides almost exactly like our favorite analog trail bike. The Shuttle SL is ready for big days out on the trail where smashing climbs and sending side hits are both on the menu. 132mm of Fox Factory-supported DW-Link rear travel paired with the 60Nm motor offers up plenty of power and pop to throw the bike around on all the new features we find out there without sacrificing traction when the trail gets steep. And although it’s nearly impossible to fully drain the battery, if we find ourselves miles from the trailhead with no juice left, the Shuttle SL is virtually drag-free with the pedal assist turned off.


The premium Shuttle SL Team XTR build is all about sending new lines and having fun on the trail. The 12-speed XTR drivetrain brings the ultra-smooth, reliable shifting that we expect from Shimano to a lightweight package that doesn’t sacrifice any gear range. An Ebike-tuned Fox Factory 36 fork with 150mm of travel supports the front end to absorb those big hits on the descent, while a set of 29er Reynolds Blacklabel carbon wheels laced to Industry Nine Hydra hubs make sure we can roll over just about anything. When we find ourselves having to stop on a dime or dump speed quickly, 4-piston Shimano XTR brakes bolstered by a 203mm rotor up front and a 180mm rotor in the rear provide plenty of stopping power. A proper trail bike wouldn’t be complete without a solid dropper post, and the Fox Transfer Factory Series offers ultra-reliable modulation to get the saddle out of the way for techy rock gardens and rowdy descent. The Pivot Shuttle SL Team XTR is made to handle like a trail bike, but it's ready to take us to lines we’ve only seen in our dreams.


*Due to a high demand in the global supply chain and bike industry, material weight and exact components are subject to change. We are working diligently to keep tech specs updated, and any adjustments will be of equal or better spec level. If you have any questions, reach out to a Gearhead by chatting online or calling 1-888-276-7130.


Details

  • Superlight eMTB built to smash climbs and send bigger moves
  • Integrated Fazua 60 motor system allows unmatched weight savings
  • 450 Watts of peak power offer plenty of punch to tackle any trail
  • DW-Link suspension allows a lively feel and pedaling performance
  • Shimano XTR drivetrain provides ultra-smooth, reliable shifting
  • Carbon frame damps vibrations and is responsive
  • Fox Factory 36 fork offers 150mm of bump-busting travel
  • 29in Reynolds carbon wheels keep us rolling over any obstacle
  • Item #PIV1X03
Frame Material
carbon
Suspension
DW-Link
Rear Shock
Fox Factory Float X
Rear Travel
132mm
Fork
Fox Factory E-MTB 36
Front Travel
150mm
Headset
Pivot Precision Sealed Cartridge
Shifters
Shimano XTR, 12-Speed
Rear Derailleur
Shimano XTR, 12-Speed
Drive System
Fazua Ride 60
Motor Power
450W
Battery Type
internal, rechargeable
Battery Energy
430Wh
Max Torque
60Nm
Max Speed
20mph
Crankset
ROTOR EKAPIC E-MTB
Chainring Sizes
32t
Cassette
Shimano XTR, 12-Speed
Cassette Range
10-51t
Chain
Shimano XTR, 12-Speed
Brakeset
Shimano XTR M9120
Brake Type
4-piston, hydraulic disc
Rotors
Galfer, [front] 203mm, [rear] 180mm
Handlebar
Phoenix Team Low Rise Carbon
Handlebar Width
780mm
Grips
Phoenix Factory Lock-On
Stem
Phoenix Team Enduro/Trail
Saddle
Phoenix WTB Volt Team (medium width)
Seatpost
Fox Transfer Factory Series, 31.6mm
Seatpost Travel
[small] 150mm, [medium, large] 175mm, [x-large] 200mm
Wheelset
Reynolds Blacklabel 309/289 XC, 29in, carbon
Hubs
Industry Nine Hydra
Front Axle
15 x 110mm Boost
Rear Axle
12 x 157mm Super Boost
Tire Clearance
29 x 2.4in
Tires
[front, rear] Maxxis Dissector, WT, TR, 3C, EXO, MAXXTERRA
Tire Size
[front, rear] 29 x 2.4in
Pedals
not included
Includes
Universal Derailleur Hanger
Claimed Weight
[large] 40lb (18.16kg)
Activity
cross-country, trail
Manufacturer Warranty
[frame] 10 years
