Fox Factory suspension on the Ripley Deore build
The Ripley Deore runs dw-link suspension through 130mm of rear travel, matched to a 64.9-degree head angle and size-specific seat tube angles across five frame sizes. That per-size tuning keeps the kinematics consistent whether the frame is a Small or an Extra Large, not just scaled up in length.
What Our Gearhead® Experts Are Saying:
"Factory-series internals on the Float SL 36 give me full high- and low-speed compression adjustment instead of a single dial, so I can tune small-bump sensitivity independently from bottom-out control. That's the kind of adjustment range that changes how precisely I can dial the fork to a specific trail, not just soften or firm it overall."
Details
- Trail bike ready to climb efficiently and stay composed on the way down
- dw-link rear suspension — 130mm of travel tuned by Ibis's lighter Traction Tune shock setup
- Fox Float SL 36 fork — 140mm of Factory-series suspension up front
- Slack 64.9-degree head angle — steadies the bike at speed on rough descents
- Carbon fiber monocoque frame — keeps weight low without sacrificing stiffness
- STOW internal frame storage — fits a tube and tools, bags made with Cotopaxi
- Shimano Deore drivetrain — reliable 12-speed shifting that shrugs off trail abuse
- Ibis 933 aluminum wheels — tubeless-ready Maxxis tires front and rear
- Item #IBSB0FO
- Frame Material
- Carbon fiber monocoque
- Suspension
- dw-link
- Rear Shock
- Fox Float, Factory Series, EVOL, Traction Tune
- Rear Travel
- 130mm (5.1in)
- Fork
- Fox Float SL 36, Factory Series, Grip X
- Front Travel
- 140mm
- Headset
- Cane Creek 50, ZS44 upper/ZS56 lower
- Shifters
- Shimano Deore M6200
- Rear Derailleur
- Shimano Deore M7200 SGS
- ISCG Tabs
- ISCG 05 (tab mount sold separately)
- Crankset
- Shimano Deore M6200
- Crank Arm Length
- [Small, Medium] 165mm, [Extra Medium, Large, Extra Large] 170mm
- Bottom Bracket
- Shimano MT501, threaded 73mm BSA
- Cassette
- Shimano Deore M6200, 12-speed
- Chain
- KMC X12
- Brakeset
- Shimano Deore 6200, 4-piston
- Brake Type
- Hydraulic disc
- Rotors
- Shimano SM-RT66, 180mm
- Handlebar
- Ibis Alloy MTB Bar
- Handlebar Width
- 800mm
- Grips
- Lizard Skins Strata, single clamp
- Stem
- BLKBRD Stem
- Stem Length
- [Small, Medium] 35mm, [Extra Medium, Large, Extra Large] 50mm
- Saddle
- WTB Silverado Fusion CrMo 142
- Seatpost
- KS Vantage Dropper, 34.9mm
- Seatpost Travel
- [Small] 110-140mm, [Medium, Extra Medium] 140-170mm, [Large, Extra Large] 180-210mm
- Wheelset
- Ibis 933 Aluminum
- Hubs
- Blackbird Hubs
- Front Axle
- 15 x 110mm Boost
- Rear Axle
- 12 x 148mm Boost
- Tire Clearance
- 2.5in
- Tires
- [front] Maxxis DHR2/Forekaster, Exo, TR, [rear] Maxxis Rekon, Exo, TR
- Tire Size
- 29 x 2.4in
- Pedals
- Not included
- Extras
- STOW internal frame storage, bags made with Cotopaxi
- Activity
- Trail
- Manufacturer Warranty
- [frame, wheels, bushings] Lifetime
