ENVE
Mog Gravel Frameset

Be the first to review
$5,500.00

Style & Size:

Find your size

Quantity

Customize Your Build

Why We Like The ENVE Mog Gravel Frameset

Whether we're building up our dream gravel race bike or just an off-road machine to adventure with, we do it with the ENVE Mog Gravel Frameset. Its lightweight M.O.D. carbon fiber frame and fork are durable and comfortable, while its geometry is similar to a road bike for a fast, fun ride that features handling characteristics tuned for modern gravel riding. ENVE fully integrated the front-end to hide wires, brake hose, and housing, resulting in optimized aerodynamics and a sleeker look. Two included in-frame storage bags easily carry our gear during long bikepacking trips, and it also features on-frame storage solutions via the fork and frame rivet nut inserts.


Details

  • Elite off-road machine for gravel racing, riding, and exploring
  • Optimized for modern gravel handling with a road-like geometry
  • ENVE Gravel drop bars place riders in a better aero position
  • Features fully integrated internal wire, hose, and dropper routing
  • Includes two in-frame storage bags to hold spares, tools, and snacks
  • Designed for 700c x 40-44mm tires with a max clearance of 50mm
  • Compatible with fenders and 1x drivetrain dropper posts
  • Item #ENV2SRD
Frame Material
M.O.D. Carbon
Wheel Size
700c
Fork
ENVE M.O.D Carbon
Head Tube Diameter
1 1/8in
Headset Included
ENVE Integrated IS52/IS52 Internal Drop-In
Bottom Bracket Type
T47
Cable Routing
internal
Front Derailleur Mount
braze-on
Brake Type
flat-mount, disc
Compatible Components
[Shimano] GRX 2x, GRX 1x (max 50t chainring), [SRAM] WIDE 2x, WIDE 1x (max 50t chainring), standard 1x direct mount cranksets (max 46t chainring), [aftermarket] direct-mount cranksets (max 46t chainring, 44.5 - 45.5mm chainline)
Handlebar
ENVE Gravel
Handlebar Drop
120mm
Handlebar Width
[size 49, size 52] 42cm, [size 54, size 56] 44cm, [size 58, size 61] 46cm
Stem
ENVE Integrated Aero Road
Stem Length
[size 49] 80mm, [size 52] 90mm, [size 54, size 56] 100mm, [size 58] 110mm, [size 61] 120mm
Seatpost
ENVE
Seatpost Diameter
27.2mm
Front Axle
12 x 100mm Thru-axle
Rear Axle
12 x 142mm Thru-axle
Tire Clearance
700 x 35 - 44mm
Extras
downtube protector, 2 Cargo Bay storage bags
Includes
Universal Derailleur Hanger
Claimed Weight
[size 56] 950g
Activity
gravel
Manufacturer Warranty
5 years
SHIS
IS52/IS52
