Zipp 404 Carbon Rear Wheel - Clincher

Out of Stock

Item # ZIP0074

2011 This model is no longer in stock.

Item # ZIP0074

Description

Technology designed to make you go faster.

Zipp's catalog of wheels covers a broad spectrum, but none of them embody the ride-anywhere, race-ready mentality of the 404 Carbon Clincher Rear Wheel. The aerodynamic advantages of the 404 clincher are no different from that of the 404 tubular. You get the same rim depth, 58mm, and like the tubular, the clincher rim has a gentle convex wall curvature that allows for a regenerative airflow with an optimized trailing edge. Air whips over the rim with minimal turbulence. No other wheel rips through the wind with less resistance. You get the same golf ball-like dimples to eliminate the low-pressure wake on the rim, thereby substantially reducing wheel drag. And you get the same bladed Sapim CX-Ray spokes. When sustainable high-end speed is your primary concern, the 404 is the world's finest wheelset.

Most carbon fiber rim manufacturers produce their clincher rims the same way -- they bond a non-structural carbon fairing to an aluminum rim. The Zipp 404 Deep-V clincher is completely different. All Zipp carbon fiber clincher rims employ m2cm technology -- the carbon rim is hand built and molded inside a precision alloy extrusion (the rim itself) in a single seamless procedure. The resulting co-molded rim has unparalleled stiffness and durability. The precision machined, perfectly parallel braking surface is as true and as receptive the braking power as a Mavic Open Pro rim.

The 404's are lightweight by clincher standards, but the only penalty you pay for the convenience of clinchers is the slight extra weight of the alloy braking surface. At 1712g, you're in the same ballpark as Mavic Ksyriums and Campy Eurus wheels, but the aerodynamic advantage of the 404 is enormous.

Who needs a 404 clincher the most? Time trialists and breakaway-style riders who want the aerodynamic edge, but who want the easy maintainability of clinchers. The wheel has 20 spokes on Zipp's 188 rear hub. The rim attaches to the hub via Sapim CX Ray spokes with Sapim aluminum nipples. A Zipp steel skewer rounds out the package. Choose between Campagnolo or Shimano/SRAM compatible freehub bodies. They come standard in spoke drilling of 18/24.

  • Zipp’s 88 (named for weight in grams) hub features an adjustable bearing preload that can be set after the skewer is clamped
  • Zipp 188 hubs use grade 10 Swiss steel bearings for smoothness that lasts a lifetime
  • Aero nuts used to adjust preload can be rotated for extra wind-slicing aerodynamics
  • Oversized 17mm axle is made from Z310.9 alloy for ultimate durability and stiffness
  • Zipp’s patented ABLC dimple technology offers even smoother airflow across the rim for maximum aerodynamics


Tech Specs

Material:
carbon
Rim Width:
22.5 mm
Rim Depth:
58 mm
Front Spoke Count:
20
Spoke Material:
stainless steel
Spoke Nipple Material:
aluminum
Wheelbag:
no
Front Weight:
886 g
Recommended Use:
cycling
Manufacturer Warranty:
2 years

What community has to say

What do you think of the

Zipp 404 Carbon Rear Wheel - Clincher

? Share a...

Write a review

No file chosen

Rather attach a photo from another website?

Rather attach a photo from your computer?

  • Product review:
  • Share a video
  • Share a photo

How familiar are you with the product?(Optional)

Invalid filetype.

Save

Here's what others have to say...

Is this a wheelset or just the front ? I...

Posted on

Is this a wheelset or just the front ? I am confused, the specs have it as front 20 spokes, but in your option selection is for campy/shimano.

Please advise.

Responded on

The remaining inventory is either a Shimano or Campy rear wheel. We did have a front wheel for sale as well but it is now sold out.

5 5

Best Wheels Ever

These are the best wheels I have ever ridden. I rode them all of last year as my everyday wheel set without any problems, potholes gravel roads and all.
I train with a friend who is about the same weight and has the same bike, on down hill runs he needs to peddle when I coast. The difference is astounding.

3 5

Light, but fragile

These wheels are light and fast, but they are fragile. I weigh 140 lbs and I blew up the rim when i hit a pot hole in a race. Interestingly I did not flat, but the rim was destroyed. They work great, but keep them on smooth roads.
